24V Brushed DC Motor Drive Solution for Pump Equipment
2026-10-16
To meet OEM pump customers’ requirements for steady torque output, low‑noise performance and compact installation, DEHE MOTOR presents the DH‑42ZY118D024‑01 brushed DC motor solution for fluid pump systems, delivering consistent fluid transfer and reliable operation.
- Fluctuating pump load requires stable torque to avoid flow pulsation
- Limited internal equipment space calls for compact flange‑mount structure for easy integration
- Low‑noise operation, safety insulation and ingress protection are required for end devices
- Compatible with common 24VDC industrial power supply
This 42‑mm flange‑mount brushed DC motor runs at 24VDC, rated speed 3200RPM with rated torque 0.123N·m, stall torque 0.75N·m to handle pump startup and shock load. Output shaft made of AISI 316L stainless steel resists corrosion in fluid‑related environments. IP30 protection & Class‑B insulation, max noise 50dB@30cm, well‑suited for intermittent long‑time pump operation.
Dosing pumps, peristaltic pumps, small fluid transfer pumps, water‑treatment metering pumps and other fluid‑handling devices.
Standard samples available for validation. Custom options including shaft style, cable length and mounting dimensions to match different pump mechanical interfaces.
DH‑42ZY118D024‑01 is a proven DC drive for pump OEM projects, balancing performance, assembly‑friendliness and cost‑efficiency to accelerate your fluid‑handling product development.
